| Product | Image |
|---|---|
|
|  |
|
|  |
 | |
| 4) 2 inch 480*360 IPS LCD |  |
| Panel From | Century/Hannstar |
|---|---|
| Panel Size | 2.0 inch |
| Panel Model | CT020TN01 |
| LCM Model | VIS020TN02 |
| Panel Type | a-Si TN TFT-LCD, LCM module |
| Resolution | 176(H) X 220(V) |
| Luminance | 250 cd/m² (Typ.) |
| Display Area | 31.68*39.60(mm) |
| Outline | 38.03*51.65*2.5(mm) |
| Interface Type | 40 pins MCU/SPI |
| View Direction | 12 o’clock |
| Touchscreen | Optional |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Pin No. | Symbol | I/O | Function |
| 1-8 | DB15-DB8 | I | Data pin |
| 9 | GND | P | Ground. |
| 10-17 | DB7-DB0 | I | Data pin |
| 18 | IOVCC | P | Digital IO Pad power supply |
| 19 | VCC | P | Power supply |
| 20 | RD | I | Read enable pin I80 parallel bus system interface |
| 21 | WR | I | Write enable pin I80 parallel bus system interface |
| 22 | RS | I | Command / parameter or display data selection pin |
| 23 | CS | I | Chip select signal |
| 24 | RESET | I | Reset the display |
| 25 | IM0 | I | Select the interface . |
| 26 | GND | P | Ground. |
| 27 | LEDA | P | LED back light(Anode) |
| 28-30 | LEDK1-LEDK3 | P | LED back light(Cathode) |
| 31-40 | NC | – | No Connection |
This 2 inch TFT LCD touch display adopts IPS type LCD with 240*320 resolution. We can guarantee 5+ years supply of this LCD.
Based on this LCD’s IPS display and stability, it can be used in a wide range of instruments, smart homes and devices.
Flexible PCB dimension&combination and CTP/ RTP touch can all be customized according to your needs.
We offer a choice of Soldering, Plugging or Connector connections.
We also offer a choice of 3+ different case sizes to better fit your product and save on unnecessary customisation costs.
| Panel From | HSD |
|---|---|
| Panel Size | 2 inch |
| IC | ST7789V |
| LCM Model | VIS020A3 |
| Panel Type | a-Si IPS TFT-LCD |
| Resolution | 240(H) X 320(V) |
| Luminance | 400 cd/m² (Typ.) |
| Display Area | 30.6*40.8(mm) |
| Outline | 35.7*51.2*2.2(mm) |
| Outline 2 | 34.5*48.8*2.21(mm) |
| Outline 3 | 34.76*47.86*1.95(mm) |
| Interface Type | 4 line SPI / 8 bit 8080(MCU) |
| Connection | Soldering/Plugging/Connector |
| View Direction | All |
| Touchscreen | CTP / RTP(optional) |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Please contact us for more accurate PDF datasheets, thanks.
This 2 inch TFT LCD touch display adopts IPS type LCD with 320*240 resolution. We can guarantee 5+ years supply of this LCD.
Based on this LCD’s Horizontal IPS display characteristic, it is particularly suitable for products that require a horizontal display. But it is more expensive than the vertical display 2 inch LCD.
Flexible PCB dimension&combination and CTP/ RTP touch can all be customized according to your needs.
We offer a choice of Soldering, Plugging or Connector connections.
| Panel From | HSD/IVO |
|---|---|
| Panel Size | 2 inch |
| LCM Model | VIS020H32-01 |
| Panel Type | a-Si IPS TFT-LCD |
| Resolution | 320(H) X 240(V) |
| Luminance | 350 cd/m² (Typ.) |
| Display Area | 40.8*30.6(mm) |
| Outline | 46*40.9*2.53(mm) |
| Interface Type | 4 line SPI / 8 bit 8080(MCU) |
| Connection | Soldering/Plugging/Connector |
| View Direction | All |
| Touchscreen | CTP / RTP(optional) |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
Please contact us for more accurate PDF datasheets, thanks.
VIS020IPS01 is a TFT LCD module model that adopts a 2.0 inch IPS type LCD with 480*360 resolution. CTP (Capacity Touch Panel) and RTP(Resistive Touch Panel) can be added according to user requirements. This 2.0 inch LCD is mainly developed for industrial display, and we can guarantee a stable supply of this LCD display module throughout the life cycle of your products.
Based on the LCD’s wide view range, excellent storage and operating temperature range, this type of LCD display module can be widely used in smart homes, pos machines, industrial instruments (meters), and small medical equipment and other products.
FPCA shape alignment, backlight dimension, and touch panel can all be customized according to your needs.
| Panel From | Century/HSD |
|---|---|
| Panel Size | 2.0 inch |
| IC Model | ST7701S |
| LCM Model | VIS020IPS01 |
| Panel Type | a-Si IPS TFT-LCD, LCM module |
| Resolution | 480(H) X 360(V) |
| Luminance | 500 cd/m² (Typ.) |
| Display Area | 40.82(H)*30.62(V) (mm) |
| Outline | 43.95(H)*38.80(V)*2.10(T) (mm) |
| Interface Type | 39 pins RGB |
| View Direction | ALL |
| Touch screen | Optional |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Pin No. | Symbol | Functional |
| 1 | GND | Ground |
| 2 | VDD_TP | Power supply for touch panel |
| 3 | SCL_TP | Serial clock signal |
| 4 | SDA_TP | Serial DATA signal |
| 5 | INT_TP | Interrupt signal for touch panel |
| 6 | RESET_TP | Reset signal for TP |
| 7 | GND | Ground |
| 8 | VCC | Power supply |
| 9 | IOVCC | Power supply FOR I/O |
| 10 | VSYNC | Vync signal for RGB |
| 11 | HSYNC | Hysnc signal for RGB |
| 12 | DCLK | Dot clock signal for RGB |
| 13 | DE | Dats enable signal for RGB |
| 14-29 | DB0—DB15 | Data bus signal |
| 30 | RESET LCM | Reset signal for LCM |
| 31 | CS | Chip select signal |
| 32 | SCL | Serial clock signal |
| 33 | SDA | Serial data signal |
| 34 | GND | Ground |
| 35 | GND | Ground |
| 36 | LEDK | Backlight negative |
| 37 | LEDK | Backlight negative |
| 38 | LEDA | Backlight anode |
| 39 | LEDK | Backlight anode |
